Specifications
Image Sensor: 1/2.8″ Progressive Scan CMOS; Max. Resolution: 1920 × 1080; Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR; Shutter Speed: 1/1 s to 1/30,000 s; Day & Night: IR cut filter; Zoom: 25 × optical, 16 × digital; Slow Shutter: Yes; Focal Length: 4.8 to 120 mm; FOV: Horizontal FOV 54.9° to 2.7°, vertical FOV 31.5° to 1.5°, diagonal FOV 62.3° to 3.1°; Focus: Auto, semi-auto, manual; Aperture: Max. F1.6; Zoom Speed: Approx. 3.4 s; Supplement Light Type: IR; Supplement Light Range: IR Distance: up to 50 m; Smart Supplement Light: Yes; IR Wavelength: 850 nm; Movement Range (Pan): 0° to 360°; Movement Range (Tilt): -5° to 90°; Pan Speed: Pan speed: configurable from 0.1° to 300°/s; preset speed: 350°/s; Tilt Speed: Tilt speed: configurable from 0.1° to 160°/s, preset speed 200°/s; Proportional Pan: Yes; Presets: 300; Preset Freezing: Yes; Patrol Scan: 8 patrols, up to 32 presets for each patrol; Pattern Scan: 4 pattern scans, record time over 10 minutes for each scan; Park Action: Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan; 3D Positioning: Yes; PTZ Status Display: Yes; Scheduled Task: preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust; Power-off Memory: Yes; Main Stream: 50 Hz: 50 fps (1920 × 1080, 1280 × 960, 1280 × 720);
60 Hz: 60 fps (1920 × 1080, 1280 × 960, 1280 × 720)
*High frame rate is supported under certain settings.; Sub-Stream: 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288);
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240); Third Stream: 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288);
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240); Video Compression: Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264/MJPEG; H.264 Type: Baseline Profile/Main Profile/High Profile; H.265 Type: Main profile; Scalable Video Coding (SVC): H.264 and H.265 encoding; Region of Interest (ROI): 8 fixed regions for each stream; Audio Compression: G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM/AAC-LC; Audio Bit Rate: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/128 to 1024 Kbps (PCM)/16 to 64 Kbps (AAC-LC); Audio Sampling Rate: AAC-LC: 16 kHz, 32 kHz, 48 kHz; MP2L2: 16 kHz, 32 kHz, 48 kHz; PCM: 8 kHz, 16 kHz, 32 kHz, 48 kHz; Environment Noise Filtering: Yes; Protocols: IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour,WebSocket,WebSockets; Simultaneous Live View: Up to 20 channels; API: Open Network Video Interface (Version 19.12), Profile S, Profile G, Profile T), ISAPI, SDK, ISUP; User/Host: Up to 32 users; 3 user levels: administrator, operator, and user; Security: Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, control timeout settings, security audit log, TLS 1.2, host authentication (MAC address); Network Storage: NAS (NFS, SMB/CIFS), auto network replenishment (ANR); Client: iVMS-4200, HikCentral Pro, Hik-Connect; Web Browser: IE 10 to 11, Chrome 57+, Firefox 52+, Safari 11+; Image Parameters Switch: Yes; Image Settings: Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser; Day/Night Switch: Day, Night, Auto, Schedule; Wide Dynamic Range (WDR): 120 dB; SNR: ＞52 dB; Defog: Digital Defog; Image Enhancement: BLC, HLC, 3D DNR; Privacy Mask: 24 programmable polygon privacy masks, mask color or mosaic configurable; Regional Focus: Yes; Regional Exposure: Yes; Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port; On-board Storage: Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB; Audio: 1 input (line in), max. input amplitude: 1Vrms, input impedance: 4.7 KΩ ± 5%; 1 output (line out), line level, output impedance:100Ω±5%; Alarm: 2 inputs, 2 outputs; Reset: Yes; Basic Event: Motion detection, video tampering alarm, exception, alarm input and output; Smart Event: line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection; Linkage: Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, and PTZ actions (such as preset, patrol scan, pattern scan); Smart Tracking: Manual tracking,auto-tracking; Face Capture: Detects up to 5 faces simultaneously,
Supports detecting, tracking, capturing, grading, selecting of face in motion, and outputs the best face picture; Power: 12 VDC, Max. 24 W; PoE (802.3at); Dimension: Ø 169 mm × 161 mm (Ø 6.65″ × 6.34″); : Approx. 2.45 kg (5.40 lb.); Operating Condition: -30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing); General Function: Mirror, password protection; Protection: IP66 (IEC 60529-2013), TVS 6000V lightning protection, surge protection and voltage transient protection; Application Scene: –
